This submersible pump is designed for extracting clean water from drilled wells or cisterns, at medium or great depths. Thanks to its multistage construction and series-mounted impeller system, this pump generates high pressures and ensures a stable flow rate.
Thanks to its 4” diameter, it is compatible with most piping used for drilled wells, ensuring easy handling and installation.
With a power of 1100 W, the submersible pump can lift water to a maximum height of 96 m, providing a maximum flow rate of 100 L/min.
The stainless steel body offers superior corrosion resistance, longer service life and increased reliability, making the pump ideal for prolonged use in outdoor humidity conditions.
The control panel is the essential element for controlling and protecting the submersible pump, ensuring safe and efficient operation of the equipment. It allows easy operation of the pump and protects the motor against overloads or possible electrical faults thanks to the fuse. The panel is equipped with a main ON/OFF switch, positioned visibly and easily accessible, which allows the pump to be started and stopped quickly and safely.
Technical data:
Rated power: 1100 W
Maximum immersion depth: 100 m
Maximum pumping head: 96 m
Maximum flow rate: 100 L/min
Maximum pressure: 9.6 bar
Number of impellers: 14
Power cable length: 20 m
Maximum suspended particle content: 250 g/m³
Maximum temperature of pumped liquid: 35 °C
Connection: 1 ¼”
Protection rating: IP68
Do not use the product for pumping hydrocarbons (fuels, oils, solvents, etc.) or other liquids!
